Machine data
2.4 Axis-specific machine data
Parameter Manual
278
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
When a spindle is stopped (M5), the path feed is disabled (positioning axes
continue traversing) if MD35510 $MA_SPIND_STOPPED_AT_IPO_START is enabled
and the spindle is in control mode.
When the spindle has come to a standstill (NC/PLC interface signal DB390x
DBX1.4 (Axis/spindle stationary) enabled), the path feed is enabled.
Related to:
MD35500 $MA_SPIND_ON_SPEED_AT_IPO_START (feed enable for spindle in setpoint
range)
Description: Limit speed values for tapping without compensating chuck with G331/G332.
The maximum speed of the linear motor characteristic range (constant acceler-
ation capacity) must be specified depending on the gear stage.
35510 SPIND_STOPPED_AT_IPO_START A03, A06, A10 S1
- Feedrate enable for spindle stopped BOOLEAN Reset
CTEQ
-- FALSE0 - 2/2
35550 DRILL_VELO_LIMIT A06, A11, A04 -
rev/min Maximum speeds for tapping DOUBLE NEW CONF
CTEQ
- 6 10000., 10000.,
10000., 10000.,
10000., 10000.
0.1 - 1/1
