PLC User Interface
5.5 Signals from/to HMI
Parameter Manual
432 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
5.5.7 Signals from maintenance planners
5.5.8 Signals from operator panel (retentive area)
5.5.9 General selection/status signals from HMI (retentive area)
DB1800 Warnings/Alarms [r]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
3000 Alarm 8 Alarm 7 Alarm 6 Alarm 5 Alarm 4 Alarm 3 Alarm 2 Alarm 1
3001 Alarm 16 Alarm 15 Alarm 14 Alarm 13 Alarm 12 Alarm 11 Alarm 10 Alarm 9
3002 Alarm 24 Alarm 23 Alarm 22 Alarm 21 Alarm 20 Alarm 19 Alarm 18 Alarm 17
3003 Alarm 32 Alarm 31 Alarm 30 Alarm 29 Alarm 28 Alarm 27 Alarm 26 Alarm 25
DB1900 Signals from operator panel [r/w]
HMI -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Switch over
Machine/
Work
Simulation
active
1
2
3
4
6
7
DB1900 Signals from HMI [r]
HMI -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000
1001
1002
1003 Axis number for handwheel 1
Machine
axis
Handwheel
selected
Contour
handwheel
CBA
1004 Axis number for handwheel 2
Machine
axis
Handwheel
selected
Contour
handwheel
CBA
1005
