Electrical Installation Manual
Operating Instructions, 12/2014, 6FC5397-2EP10-0BA0
41
Technical specifications
4
PPU MCP
Design data
Dimensions (W x H x D) (in mm) 420 x 200 x 104 420 x 120 x 58
Weight (in kg) 3.06 0.86
Cooling method Self-cooling Self-cooling
Degree of protection Front side: IP54
Back side: IP20
Front side: IP54
Back side: IP00
Electrical data
Supply voltage 24 V DC
(permissible range: 20.4...28.8 V) Powered by PPU
Ripple 3.6 Vpp -
Current consumption from 24 V Basic configuration
typically 1.5 A (inputs/outputs open) -
Non-periodic overvoltage 35 V
(500 ms duration, 50 s recovery time) -
Total starting current 1 A -
Rated input current 2 A 0.5 A
Power loss max. 50 W max. 5 W
Interference immunity in accordance with
EN 61800-3
≥ 20 μs ≥ 20 μs
Overvoltage category 3 3
Degree of pollution 2 2
Transport and storage conditions
Temperature -20 °C to +60 °C -20 °C to +60 °C
Vibration resistance (transport) 5 Hz~9 Hz: 3.5 mm
9 Hz~200 Hz: 1g
5 Hz~9 Hz: 3.5 mm
9 Hz~200 Hz: 1g
Shock resistance (transport) 10 g peak value, 6 ms duration
100 shocks in each of the 3 axes vertical to one another
Free fall < 1m <1m
Relative humidity 5% to 95%, without condensation 5% to 95%, without condensation
Atmospheric pressure 1060 hPa to 700 hPa (corresponds to an altitude of 3,000 m)
Ambient operating conditions
Temperature 0 °C to 45 °C
Atmospheric pressure From 1080 hPa to 795 hPa From 1080 hPa to 795 hPa
Vibration resistance (in operation) 10 Hz~58 Hz: 0.35 mm
58 Hz~200 Hz: 1g
10 Hz~58 Hz: 0.35 mm
58 Hz~200 Hz: 1g
