4.5 SIMATIC IoT2040
Overview
This chapter provides information on how to use SIMATIC IoT2040 to install a proxy.
With IoT2040, you connect SINUMERIK controls with MindSphere that do not support TLS 1.2.
TLS 1.2 is required for the connection to IoT2040.
Hardware setup
SIMATIC IoT2040 (6ES7647-0AA00-1YA2) is used to setup this configuration.
Products (
https://mall.industry.siemens.com/mall/de/WW/Catalog/Products/10321262)
To understand additional preconditions that are required, read the following Chapter: System
requirements (Page 14), paragraph "SIMATIC IoT2040".
4.5.1 SIMATIC IoT2000 SD card example image on IoT2040
Procedure
Download the SIMATIC IoT2000 SD-Card example image from the following link:
SD card image (
https://support.industry.siemens.com/cs/document/109741799/)
- OR -
From the .zip file:
Image Zip example (https://support.industry.siemens.com/cs/attachments/109741799/)
Roadkil's disk image
1. Use the "Roadkil's Disk Image" to install the image.
Download the standalone version at the following link:
Roadkil Disk Image (http://www.roadkil.net/program.php/P12/Disk%20Image)
Note
Erase all partitions
To avoid malfunctions, erase all existing partitions on the SD card before you start.
2. Select the "Write Image" tab.
3. Select "Physical Disk" so that the image can be written to it.
Note
Selection of the physical disk
Ensure that the SD card is selected.
Installation/configuration
4.5 SIMATIC IoT2040
Manage MyMachines /Remote - installation in existing control environments
36 Application examples, 10/2018, A5E45211403B AB
