<VirtualHost *:8082>
ServerName gateway.eu1.mindsphere.io/
SSLProxyEngine On RequestHeader set Front-End-Https "On"
ProxyPass / http://gateway.eu1.mindsphere.io/
ProxyPassReverse / http://gateway.eu1.mindsphere.io/
</VirtualHost>
4.5.5 Configuring SINUMERIK controls
4.5.5.1 Overview
Introduction
This chapter describes configuring the following SINUMERIK control for use of an Apache
proxy on the IoT2040.
● SINUMERIK control with HMI-Advanced - Setting the proxy (Page 76)
● SINUMERIK control with SINUMERIK Operate - Setting the proxy (Page 85)
The following port is configured for MindSphere V3 Livesystem:
● Port 8082
Configure the URL for connection to MindSphere with http - not with https.
● http://gateway.eu1.mindsphere.io/api/agentcom-mmmops/v3/ws11
4.5.5.2 SINUMERIK control with HMI-Advanced - Setting the proxy
Procedure
1. Start the PCU in service mode.
2. Open "Add or Remove Programs" in Windows and select "SINUMERIK Integrate Client".
Click "Change".
Installation/configuration
4.5 SIMATIC IoT2040
Manage MyMachines /Remote - installation in existing control environments
76 Application examples, 10/2018, A5E45211403B AB
