Connecting
7.5 DRIVE CLiQ components
NCU 7x0.2
54 Manual, 02/2011, 6FC5397-0AP20-0BA0
7.5.2 Connectable DRIVE-CLiQ components
Components
As a rule, all SINAMICS components approved for SINUMERIK can be connected using the
DRIVE-CLiQ interface.
Table 7- 8 Components with DRIVE-CLiQ
Component Description
NX10/15 Drive expansion module for up to 6 axes
SINAMICS S120, system components of the booksize and chassis formats
Smart / Active / Basic
Line Module
Line Modules provide the central power supply to the DC link.
Single / Double Motor
Module
Motor Modules draw their power from the DC link to supply the
connected motors.
SINAMICS S120, additional system components
SMC10/20/30 Cabinet-Mounted Sensor Modules are needed when a motor with a
DRIVE-CLiQ interface is not available and when external encoders
are required in addition to the motor encoder.
SME20/25 Measuring systems outside the cabinet can be connected directly to
the Sensor Module External.
DMC20/DME20 DRIVE-CLiQ Hub Modules are used to implement star-shaped
distribution of a DRIVE-CLiQ line.
TM15 The number of available digital inputs and outputs within a drive
system can be expanded with the Terminal Module.
Additional references
● For information on SINAMICS S120 line modules and Motor Modules, please refer to the
– Equipment Manual Booksize Power Units
– Chassis Power Units Equipment Manual
● You can find information on all other modules in the SINAMICS S120 "Control Units and
Additional System Components" Manual.
