Siemens SITOP PSU6200 User Manual

SITOP PSU6200 1ph
Manual, 03.2019, A5E44623264-1-76
43
Technical data
6
Note
Technical data apply for a rated input voltage, rated load and 25
°C ambient temperature if
nothing else is
specified.
6.1 Input
6EP3323-7SB00-0AX0 (12 V/7 A)
6EP3324-7SB00-3AX0 (12 V/12 A)
Rated voltage U
in rated
AC: 120 V - 230 V; DC: 120 V - 240 V
AC: 120 V - 230 V; DC: 110 V - 240 V
Voltage range
• Remark
AC: 85 V - 264 V; DC: 99 V - 275 V
Derating at U
in
< 102 V AC: max. 80 %
I
out rated
AC: 85 V - 264 V; DC: 85 V - 275 V
-
Wide-range input
Yes
Connect/shutdown threshold, typical
81 V AC / 49 V AC
83 V AC / 58 V AC
Line supply buffering at I
out rated
, min
20 ms
20 ms
Power-failure buffering
at 120 V / 230 V
Rated line frequency
50 - 60 Hz
Line frequency range
47 - 63 Hz
Input current at the rated input voltage
of 120 V
1.5 A AC / 0.9 A DC 1.3 A AC / 1.4 A DC
Input current at rated input voltage
230 V
0.9 A AC / 0.5 A DC 0.8 A AC / 0.7 A DC
Inrush current limiting (25 °C), max.
29 A
6 A
I²t, at 120 V AC, max.
0.4 A
2
s
1 A
2
s
I²t, at 230 V AC, max.
1.3 A
2
s
0.5 A
2
s
Integrated input fuse
Fuse T 3.15 A
Fuse T 6 A
Protection in the line feeder cable
(IEC 898)
Recommended: Miniature circuit
breaker characteristic C, 6 A
Recommended: Circuit breaker, C
characteristic, 6 A
Power consumption (active power) at
full load
100 W 97 W
Overvoltage strength
300 V AC for 30 seconds
