Siemens SITOP PSU6200 User Manual

Technical data
6.7 Mechanical system
SITOP PSU6200 1ph
Manual, 03.2019, A5E44623264-1-76
59
6.7 Mechanical system
6EP3323-7SB00-0AX0
(12 V/7 A)
6EP3333-7LB00-0AX0
(12 V/12 A)
6EP3333-7SB00-0AX0
(24 V/3.7 A)
6EP3324-7SB00-3AX0
(24 V/5 A)
6EP3334-7SB00-3AX0
(24 V/10 A)
6EP3336-7SB00-3AX0
(24 V/20 A)
Connection system
Spring-loaded terminal
Connections: Line input L, N, PE: 1 spring-loaded terminal for 4 mm² solid and
2.5 mm² finely stranded conductors
L, N, PE: 1 spring-loaded ter-
minal for 4 mm² solid and
2.5 mm² finely stranded con-
ductors
Connections: Output +, -: 2 spring-loaded terminals each for 4 mm² solid and
2.5 mm² finely stranded conductors
+, -: 2 spring-loaded termi-
nals each for 10 mm² solid
and 6 mm² finely stranded
conductors
Connections: Auxiliary con-
tacts
Signaling contact: 2 spring-loaded terminals for 1.5 mm²
Width of the housing
35 mm
45 mm
70 mm
Height of the housing
135 mm
135 mm
135 mm
Depth of the housing
125 mm
125 mm
155 mm
Installation width
35 mm
45 mm
70 mm
Mounting height
225 mm
225 mm
225 mm
Weight, approx.
0.7 kg
0.9 kg
1.5 kg
Product feature of the hous-
ing: housing that can be
lined up next to one another
Yes
Type of mounting: Wall/panel
mounting
No
Type of mounting: Rail
mounting
Yes
Type of mounting: S7-300
rail mounting
No
Mounting
Can be snapped onto standard TH35-15/7,5 (EN 60715) mounting rails
