Siemens SITOP PSU6200 User Manual

Technical data
6.2 Output
SITOP PSU6200 1ph
46 Manual, 03.2019, A5E44623264-1-76
6.2 Output
6EP3323-7SB00-0AX0 (12 V/7 A)
6EP3324-7SB00-3AX0 (12 V/12 A)
Output
Regulated, isolated DC voltage
Rated voltage U
out rated
DC
12 V
Total tolerance, static ±
3 %
3 %
Static line regulation, approx. ±
0.1 %
0.1 %
Static load regulation, approx. ±
1 %
1 %
Residual ripple
Peak-peak, max.
150 mV 150 mV
Spikes peak-peak, max. (bandwidth,
200 MHz)
240 mV 240 mV
Adjustment range
12 - 15.5 V
Output voltage can be adjusted
Yes
Output voltage setting
Using a potentiometer
Status display LED green for 12 V O.K. LED green for 12 V O.K., diagnostics
monitor, see Chapter Status displays
and signaling (Page 12)
Signaling
Relay contact (NO contact, contact rating 60 V DC/0.3 A) for 12 V O.K.
Response when switching on/off
Overshoot of U
out
< 100 mV
Starting delay, max.
90 ms
310 ms
Start delay, typ.
30 ms
140 ms
Voltage rise
120 V / 230 V AC max.
50 ms 100 ms
Voltage rise
120 V / 230 V AC typ.
30 ms 80 ms
Rated current I
out rated
7 A
12 A
Current range
• Remark
0 ... 7 A
8.4 A to 45 °C
60 ... 70 °C derating:
3 % I
out rated
/K
0 ... 12 A
14.4 A to 45 °C
60 ... 70 °C derating:
3 % I
out rated
/K
Active power output, typ.
84 W
146 W
Overload capability (Extra Power)
10.5 A for 5 s/min
18 A for 5 s/min
Can be connected in parallel to in-
crease the power rating
No Yes
Number of devices that can be con-
nected in parallel to increase the power
rating, units
- 2
Output characteristic see Figure 6-3 Output characteristic
6EP3323-7SB00-0AX0 single operation
(Page 48)
see Figure 6-4 Output characteristic
6EP3324-7SB00-3AX0 single operation
(Page 49)
Capacitive load, max.
2 mF/A
