Engineering and remote access
3.8 OPC UA server
SITOP UPS1600 / UPS1100
168 Manual, 04.2017, A5E37775406-8-76
SITOP UPS1600 parameters in the OPC UA client
3.8.6.1
The OPC UA client uses the following symbols:
Object (supported modules)
Variable with other attributes (EURange, EngineeringUnits, EnumStrin
gs)
Information on the selected object is displayed in area "Attributes". Relationships to other
objects are displayed in area "References".
A dialog is displayed when calling a method. "InputArguments" and "OutputArguments" can
be entered here.
Values that can be changed (e.g. IP addresses or path data) can be directly edited in area
"Attributes".
BatteryChange
Boolean PropertyType
Battery capacity is insufficient to achieve the specified buffer
time.
Battery charge level in percent
BatteryChargeVoltage Float AnalogItemType Voltage used to charge battery during the constant charging
