Siemens SITOP UPS1600 User Manual

Safety, approvals, EMC
9.3 Approvals
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
223
9.3
Approvals
6EP4134-3AB00- ...
6EP4136-3AB00- ...
6EP4137-3AB00- ...
6EP4131-0GB00-0AY0
6EP4132-0GB00-0AY0
6EP4133-0GB00-0AY0
6EP4133-0JB00-0AY0
6EP4134-0GB00-0AY0
6EP4135-0GB00-0AY0
CE marking
Yes, (2004/108/EG)
Yes, (2004/108/EG and 2006/66/EG)
UL/cUL approval cULus-listed (UL 508, CSA 22.2 No. 107.1),
File E197259
cURus-Recognized (UL 1778, CSA C22.2 No.
107.1),
File E219627
Explosion protection EPS 13 ATEX 1 607 X IECEx EPS 14.0063X II
3G Ex nA nC IIC T4 Gc;
cCSAus HazLoc Class I, Div 2, Group A,B,C,D
T4;
cULus HazLoc Class I, Div 2, Group A,B,C,D
T4
EPS 13 ATEX 1 607 X IECEx EPS 14.0063X II
3G Ex nA IIC T4 Gc;
cCSAus HazLoc Class I, Div 2, Group A,B,C,D
T4;
cURus HazLoc Class I, Div 2, Group A,B,C,D
T4
6EP4133-0JB00-0AY0: No explosion protection
certification
CB certification
Yes, (IEC 60950-1)
Yes, (IEC 60950-1)
Marine approvals
GL
GL
9.4
EMC
6EP4134-3AB00- ... (10 A)
6EP4136-3AB00- ... (20 A)
6EP4137-3AB00- ... (40 A)
6EP4131-0GB00-0AY0 (1.2 Ah)
6EP4132-0GB00-0AY0 (2.5 Ah)
6EP4133-0GB00-0AY0 (3.2 Ah)
6EP4134-0GB00-0AY0 (7 Ah)
6EP4135-0GB00-0AY0 (12 Ah)
6EP4133-0JB00-0AY0
(5 Ah)
Electrostatic discharge
EN 61000-4-2
6 kV contact, 8 kV air
5 kV contact, 8 kV air
Electromagnetic fields EN 61000-4-3 80 - 1000 MHz 10 V/m
1400 - 2000 MHz 10 V/m
2000 - 2700 MHz 10 V/m
895 - 905 MHz and 1.89 GHz 10 V/m
High-speed transient disturbance
variables (burst)
EN 61000-4-4 2 kV at DC input/output
Surge voltages EN 61000-4-5 500 V symmetrical/unsymmetrical at the DC input/output, 1 kV un-
symmetrical at signal connections
