Simplex 100 User Manual

PROGRAMMING
21
To Set the Display Orientation
You must program the Simplex 100’s display to display its information based on how it is
mounted. Use the following steps to set the orientation of the display.
A. Press CHANGE once.
B. Press ACCEPT until the programming arrow appears above DISPLAY ORIENTATION.
Press CHANGE once.
• The DISPLAY ORIENTATION option begins to blink.
Press the CHANGE button until the desired number is displayed.
D. Press ACCEPT to set the DISPLAY ORIENTATION option shown on the display.
• The programming arrow disappears and the Simplex 100 displays the current time.
Note: When you have finished programming the Simplex 100, remove the release key from the
cover, then snap the cover back into place on the clock.
C.

Simplex 100 Specifications

General

Brand	Simplex
Model	100
Category	Time Clocks
Language	English
