Singer XL-420 User Manual

36
Under side
Côté de dessous
Reverso
Top side
Côté de dessus
Cara
STITCH WIDTH
LARGEUR DU POINT
ANCHO PUNTADA
STITCH LENGTH
LONGUEUR DU POINT
LARGO PUNTADA
Center position
3RVLWLRQFHQWUDOH
Aguja posicionada en el centro
ZIGZAG STITCHING
The top thread may appear on the bottom depending on the
thread, fabric, type of stitch and sewing speed, but the bobbin
thread must never appear on the top of the fabric.
SETTINGS :Presser foot - General Purpose Foot
:Thread tension control - S
is values set automatically when pattern (No. 03) is set.
The stitch length is 2 mm and the stitch width is about 5 mm.
is the selection range when setting the value manually.
ADJUSTING STITCH WIDTH AND LENGTH
3/$&(0(172)3$77(516
Stitch width of pattern increases from center needle position
as illustrated.
SATIN STITCH
7KLVLVDFORVHO\VSDFHGVWLWFKXVHGIRUDSSOLTXpEDUWDFNLQJ
etc. Slightly loosen the top thread tension for satin stitching.
Set the stitch length between 0.5 and 2.0, depending on the
weight of thread being used.
8VHDEDFNLQJRIVWDELOL]HUWRKHOSDYRLGVWLWFKHVSXFNHULQJWKH
fabric.
STITCH WIDTH
mm 0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0
0
0.3
0.5
0.8
1.0
1.3
1.5
1.8
2.0
2.5
3.0
