HGM6100N Series Genset Controller User Manual Page 12 of 47
speed running. If there is high temperature, low oil pressure, over speed and abnormal voltage
during genset running, controller can protect genset to stop (detail procedures please refer to
No.4~9 of Auto start operation). Under Manual Mode, switch won’t transfer automatically, it is
necessary to press to transfer load.
2) HGM6110: Manual Mode is active when pressing , and its indicator is illuminating. Then
press to start genset, it can automatically detect crank disconnect and accelerate to high
speed running. If there is high temperature, low oil pressure, over speed and abnormal voltage
during running, controller can protect genset to stop quickly (detail procedures please refer to
No.4~9 of Auto start operation). After genset runs well in high speed, press and gens takes
load.
3) Manual Stop: Pressing can shut down the running genset (detail procedures please refer to
No.3~7 of Auto stop operation).
4.5 EMERGENCY START
In manual mode, pressing and simultaneously can compel genset to start. The controller
won’t judge whether the controller has started successfully according to disconnect conditions and the
disconnection of starter needs to be controlled by operators. When operators observed the genset has
started successfully, loose the keys and the controller enters safety delay with start no outputting.
5 PROTECTION
5.1 WARNINGS
When controller detects the warning signal, the genset only sends alarm and not stops. The alarms
are displayed in LCD.
Table 4 – Controller Warning Alarms
No.
Items
Description
1
Loss of Speed Signal
When the speed of genset is 0 and speed loss delay is 0, controller will
send warning alarm signal and it will be displayed in LCD.
2
Genset Over Current
When the current of genset is higher than threshold, over current type is
DMT and delay is 0, controller will send warning alarm signal and it will be
displayed in LCD.
3
Fail to Stop
When genset cannot stop when ETS delay/after stop delay is over,
controller will send warning alarm signal and it will be displayed in LCD.
4
Low Fuel Level
When the fuel level of genset is lower than threshold or low fuel level
warning is active, controller will send warning alarm signal and it will be
displayed in LCD.
5
Failed to Charge
During genset normal running process, when the voltage difference
