HGM6100N Series Genset Controller User Manual Page 19 of 47
7 PARAMETER RANGE AND DEFINITION
7.1 PARAMETER CONTENT AND RANGE TABLE
Table 7 – Parameter Content and Range
No.
Items
Range
Default
Description
1
Mains Normal Delay
(0-3600)s
10
The delay from abnormal to normal or from
normal to abnormal. It is used for ATS
(automatic transfer switch) control.
2
Mains Abnormal
Delay
(0-3600)s
5
3
Mains Under Voltage
(30-60000)V
184
When mains voltage is under the point, mains
under voltage active. When the value is 30,
mains under voltage disabled. Return
difference is 10V.
4
Mains Over Voltage
(30-60000)V
276
When mains voltage is greater than the point,
mains over voltage active. When the point is
60000V, mains over voltage disabled. Return
difference is 10V.
5
Transfer Delay
(0-99.9)s
1.0
It’s the delay from mains open to generator
closed or from generator open to mains
closed.
6(1)
Start Delay
(0-3600)s
1
Time from mains abnormal or remote start
signal is active to start genset.
7(2)
Stop Delay
(0-3600)s
1
Time from mains normal or remote start
signal is inactive to stop genset.
8(3)
Start Times
(1-10) times
3
When engine start failure, it’s the maximum
cranking times. When setting crank times out,
controller sends start fail signal.
9(4)
Preheat Delay
(0-300)s
0
Time of pre-powering heat plug before starter
is powered up.
10(5)
Cranking Time
(3-60)s
8
Time of starter power up each time.
11(6)
Crank Rest Time
(3-60)s
10
The second waiting time before power up
when engine start fail.
12(7)
Safety On Time
(1-60)s
10
Alarm for low oil pressure, high temp, under
speed, under frequency/voltage, failed to
charge are all inactive.
13(8)
Start Idle Time
(0-3600)s
0
Idle running time of genset when starting.
14(9)
Warming Up Time
(0-3600)s
10
Warming time between genset switch on and
high speed running.
15(10)
Cooling Time
(3-3600)s
10
Time for cooling before stopping.
16(11)
Stop Idle Time
(0-3600)s
0
Idle running time when genset stop.
17(12)
ETS Solenoid Hold
(0-120)s
20
Stop electromagnet’s power-on time when
genset is stopping.
