Smartgen HGM6100N Series User Manual

HGM6100N Series Genset Controller User Manual Page 46 of 47
13.18 YUCHAI
It is suitable for BOSCH common rail electronic-controlled engine.
Table 38 – Engine 42 Pins Port
Terminals of controller
Engine 42 pins port
Remark
Configurable output 1
1.40
Set configurable output 1 as “Fuel Relay
Output”.
Connect to engine ignition lock.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1.35
Using impedance 120Ω connecting line.
CAN(L)
1.34
Using impedance 120Ω connecting line.
Table 39 – Engine 2 Pins Port
Battery
Engine 2 pins
Remark
Battery negative
1
Wire diameter 2.5mm
2
.
Battery positive
2
Wire diameter 2.5mm
2
.
Engine type: BOSCH.
13.19 WEICHAI
It is suitable for Weichai BOSCH common rail electronic-controlled engine.
Table 40 – Engine Port
Terminals of controller
Engine port
Remark
Fuel relay output
1.40
Connect to engine ignition lock.
Starting relay output
1.61
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1.35
Using impedance 120Ω connecting line.
CAN(L)
1.34
Using impedance 120Ω connecting line.
Engine type: GTSC1.
NOTE: If there is any question of connection between controller and ECU communication, please feel free to contact
Smartgen service.
