7.4 SENSOR SELECTION
Table 10 – Sensor Selection
No.
Items
Content
Description
1
Temperature
Sensor
0 Not used
1 User Configured (Resistance Type)
2 VDO
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 User Configured (4-20mA)
10 User Configured (0-5V)
11 Digital Closed
12 Digital Open
13 Reserved
14 Reserved
Defined input resistance range is
0Ω~6000Ω, factory default is SGX
sensor.
2
Pressure
Sensor
0 Not used
1 User Configured (Resistance Type)
2 VDO
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 User Configured (4-20mA)
10 User Configured (0-5V)
11 Digital Closed
12 Digital Open
13 VDO 5Bar
14 Reserved
Defined input resistance range is
0Ω~6000Ω, factory default is SGX
sensor.
3
Fuel Level
Sensor
0 Not used
1 User Configured (Resistance Type)
2 SGH
3 SGD
4 User Configured (4-20mA)
5 User Configured (0-5V)
6 Digital Closed
7 Digital Open
Defined input resistance range is
0Ω~6000Ω, factory default is SGD
sensor.
NOTE: It needs special instructions for ordering when the genset uses 4-20mA or 0-5V sensors.
