HGM6100N Series Genset Controller User Manual Page 27 of 47
7.3 DEFINED CONTENTS OF PROGRAMMABLE INPUT 1-5
Table 9 – Defined Contents of Programmable Input 1-5 (All Ground (B-) Connected Active)
No.
Items
Description
0
Not Used
1
High Temperature Shutdown
If the signal is active after safety run delay over, genset will
immediately alarm to shutdown.
2
Low Oil Pressure Shutdown
3
Warn Input
Only warning, not shutdown.
4
Shutdown Input
If the signal is active, genset will immediately alarm to
shutdown.
5
WTH STOP by Cool
During engine running and the input is active, if high
temperature occurs, controller will stop after high speed
cooling; when the input is disabled, controller will stop
immediately.
6
Generator Closed Auxiliary
Connect to auxiliary port of gen load breaker.
7
Mains Closed Auxiliary
Connect to auxiliary port of mains load breaker.
8
Inhibit WTH STOP
When it is active, high oil temperature stop is inhibited. See
NOTE2 of Table 7 for more information.
9
Inhibit OPL STOP
When it is active, low oil pressure stop is inhibited. See NOTE3
of Table 7 for more information.
10
Remote Start
In Auto mode, when input active, genset can start and take
load after genset is OK; when input inactive, genset will stop
automatically.
11
Fuel Level Low Warning
Connected to sensor digital input. The controller sends an
warning alarm signal when active.
12
Coolant Level Low Warning
13
Fuel Level Low Shutdown
Connected to sensor digital input. The controller sends an
shutdown alarm signal when active.
14
Coolant Level Low Shutdown
15
Inhibit Auto Start
In Auto Mode, when the input is active, no matter mains normal
or not, genset won’t start. If genset is in normal running, stop
process won’t be executed. When input is disabled, genset will
automatically start or stop judging by mains normal or not.
16
Remote Control
All buttons in panel is inactive except and
Remote Mode is displayed on LCD. Remote module can switch
module mode and start/stop operation via panel buttons.
17
Charge Alt Fail IN
Connect to failed to charge output.
18
Panel Lock
All keys in panel are inactive except and there
is in the right of fifth row in LCD when input is active.
19
Alarm Mute
Can prohibit “Audible Alarm” output when input is active.
20
Idle Control Mode
In this mode, under voltage, under frequency and under speed
are not protected.
21
60Hz Select
It is used for J1939 engine with CANBUS port, when input is
