SMC Networks EX245-FPS1 User Manual

- 104 -
No.EX##-OMY0004
20. Appendix D: Diagnostic messages for parameter errors for PROFIsafe
Table 21-1 F-Parameter parameter errors
Error code
Error cause
Remedy
dec
hex
64
40
The parameterized F_Destination_Address does
not match the PROFIsafe address set on the
module (F-Module).
Make sure that the PROFIsafe address of the
module and the value in F_Destination_Address
are the same.
65
41
Invalid parameterization of
F_Destination_Address.
Addresses 0000
hex
and FFFF
hex
are not
permitted.
Correct value.
66
42
Invalid parameterization of F_Source_Address.
Addresses 0000
hex
and FFFF
hex
are not
permitted.
Correct value.
67
43
Invalid parameterization of F_WD_Time.
A monitoring time of 0 ms is not permitted.
Correct value.
68
44
Invalid parameterization of F_SIL.
The safety module (F-Module) cannot support the
required SIL.
Use a module with the required SIL.
The safety module achieves SIL 3, maximum.
69
45
Invalid parameterization of F_CRC_Length.
The CRC length generated by the safety module
(F-Module) does not match the required length.
Check device description.
70
46
Invalid F_Parameter record version.
The safety module (F-Module) version does not
match the required version.
Check device description.
Only V2 mode permitted.
71
47
The checksum determined by the safety module
(F-Module) via the PROFIsafe parameters
(CRC1) does not match the CRC1 transmitted in
the parameter telegram.
Check F-Parameters. Repeat calculation.
72
48
Device-specific diagnostics.
73
49
Save i-Parameter watchdog time exceeded.
74
4A
Restore i-Parameter watchdog time exceeded.
75
4B
Invalid S_iParCRC.
Correct value.
76
4C
F_Block_ID is not supported.
Check device description.
77
4D
Reserved.
78
4E
Reserved.
79
4F
Non-specified (unknown) error.
Table 21-2 i-Parameter parameter errors
AddValue (hex)
Error cause
Remedy
03F2
iPar_CRC is incorrect.
Check i-Parameters. Repeat calculation.
03FD
PST_Device_ID is incorrect.
Contact SMC
