- 51 -
No.EX##-OMY0004
10.2. Specifications
Table 10-1 specifications
Item
Description
EX245-FPS1
EX245-FPS2
EX245-FPS3
General
Dimensions (W x L x H) mm
85 x 148.5 x 136
Weight
1,100 g or less
1,200 g or less
Housing material
Aluminium
Max. number of modules
8
Max. number of digital inputs
128 (independent of safe inputs)
Max. number of analogue inputs
8
Max. number of digital outputs
64 (independent of solenoid valves)
Electrical
Internal current consumption at 24
VDC
350 mA or less
(via US1)
300 mA or less (via US1)
Protection against polarity reversal
Yes (US1 and US2)
Loop through current between power
connectors
16 A (for US1 and US2)
10 A (for US1 and US2)
US1
Operating voltage
24 VDC +20%/-15%
Under-voltage detection
Detected: < approx. 20.4 VDC
Cancelled: > approx. 21.6 VDC
Dropout voltage (sensors)
< approx. 17 VDC
Max. current
6 A total
US2
Operating voltage
24 VDC +20%/-15%
Under-voltage detection
Detected: < approx. 21.6 VDC
Cancelled: > approx. 22.8 VDC
Dropout voltage
(valves/loads)
< approx. 17 VDC
Max. current
4 A (independent of valves)
Voltage drop to valve supply
Max. 1.2 V at 24 VDC
Galvanic isolation
Yes (between US1 and US2)
Maintenance alarm for the Fibre-optic
cable
Yes
-
Safe input
Number of inputs
4 two-channel or 8 single-channel
Power supply voltages
Via UT1 or UT2 from US1
Permissible supply voltage for
external supply
24 VDC +20%/-15%
Power supply max current
2 A per power supply UT1
1 A per power supply UT2
3 A in total
Cross-circuit detection
Yes
Overload and short circuit protection
for UT1/UT2
Yes
Input type
PNP
Signal 1
11 to 30 V
Signal 0
-3 to 5 V
Input current signal 1
Typ. 3.8 mA at 24 VDC
Input characteristic
Complies with IEC 61131, type 3
