SMC Networks EX245-FPS1 User Manual

- 52 -
No.EX##-OMY0004
Item
Description
Safe power supply
For valve
Number of outputs
3 zones
0 VDC switch is common for all 3 zones
Number of valve coils per zone
Fixed 8 valve coils
Short circuit protection
Yes
Max current
1.5 A in total
Power source
From US2
For modules
Number of outputs
1
Short circuit protection
Yes
Max current
4 A
Power source
From US2
Solenoid valve
Applicable series
JSY3000/5000
SY3000/5000
VQC2000/4000
Max. number of solenoid valves
24 valve coils (3 zones of 8 valve coils)
Output type of solenoid
PNP
Over current protection
Yes
Over current detection
Yes
Fieldbus
Bus protocol
PROFIsafe on PROFINET
Fast Start Up
No
Media Redundancy Protocol
Yes
IRT
Yes (Only for IRT switch function)
Vendor ID
0083h
Device ID
0006h
GSD file
GSDML-V2.3-SMC-EX245-FPS-V.-.xml
Parameterisation file
EX245-FPS*_**v**_*.**.xml
Device Description file for PxC
SMC-EX245-FPS_FX_--_...zip

SMC Networks EX245-FPS1 Specifications

General

Brand	SMC Networks
Model	EX245-FPS1
Category	Control Unit
Language	English
