18.6. 120% for Full-Scale
The calibrated range of the ITV is the full-scale value/marketed value. This ITV’s range can extend
beyond the 100% mark all the way to 120% of full scale. Therefore, this ITV can deliver pressures
well beyond the calculated 100% of full-scale mark. Please note, the accuracy is not guaranteed
beyond the full-scale value. An example of where this could be useful is a process valve rate for
15PSI. Normally a 0.5Mpa ITV would be needed to meet the 15 PSI max pressure of the process
valve. Now a 0.1Mpa ITV could be used gaining 5 times better precision control of the process
valve. Please see table below for the overall values that can be set and measured for this ITV (all
values between 100% to 120% are linear) – Note 120% of the vacuum regulator is an impossibility
as there is not enough difference in the vacuum pressure for the ITV to function correctly.
ITV Unit Type – 0.1 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
100%
0.1
1.0197
1
14.5038
100
4095
120%
0.12
1.2236
1.2
17.4046
120
4914
TV Unit Type – 0.5 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
100%
0.5
5.0986
5
72.5189
500
4095
120%
0.6
6.1183
6
87.0227
600
4914
ITV Unit Type – 0.9 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
100%
0.9
9.1775
9
130.534
900
4095
120%
1.08
11.013
10.8
156.6408
1080
4914
ITV Unit Type – -80 kPa (vacuum unit)
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
100%
0.08
0.8158
0.8
11.603
80
4095
120%
0.096
0.9790
0.96
13.9236
96
4914
19. Sensitivity and Gain
These parameters can be found on the Device Control & Status webpage. They can also be set via
explicit messaging.
