7. 1.11. Alarm management
When an alarm is triggered (see alarms table), a ashing message (and his number) appears on the screen regard-
less of which mode is in use. If the alarm is critical the LED ashes, otherwise it is lit continuously. In addition to the
message and the LED warning, a buzzer will sound.
When the key is pressed, the alarm is acknowledged and the buzzer is silenced, the display remains xed (it
shows the display pages) but the LED remains ON
These different alarm displays will disappear when the alarm disappears.
In the case of multiple alarms, only the most important one will be displayed and the buzzer will sound until the last
alarm is acknowledged.
Name Message N° Meaning
Imminent stop imm stp 0 Imminent conduction shutdown
Output Isc detection out isc 1 Output in short circuit
Manual Bypass mnt bp 2 Manual bypass on
Overload I max 3 Overload at the output
Consecutive detections con det 5 Too many consecutive transfers
Auto re transfer impossible sb imp 6 Impossible Switchback
Transfer impossible trf imp 7 Impossible Transfer
Power Path 1 deteriorated pa1 at 9 Input 1 out of tolerance
Power Path 1 in short circuit pa1 sc 10 Input 1 in short circuit
Power Path 1 in failure pa1 out 11 Input 1 in failure
Power Path 2 deteriorated pa2 at 13 Input 2 out of tolerance
Power Path 2 in short circuit pa2 sc 14 Input 2 in short circuit
Power Path 2 in failure pa2 out 15 Input 2 in failure
Backfeed S1 protection open bf opn 16 Source 1 protection open
Backfeed S2 protection open bf opn 17 Source 2 protection open
Ambient temperature max tmp max 18 Max temperature reached
Preventive alarm pre alm 25 Preventive alarm
Conguration alarm cfg alm 26 Problem with the settings and parameters
Control Panel alarm hmi alm 27 Communication with screen lost
Electronic eln 28 Electronic problem
Custom input alarm cus in 29 Custom alarm
Maintenance alarm mnt alm 30 Maintenance alarm
General Alarm gen alm 31 General Alarm
