socomec STATYS series User Manual

1
STATYS 200-1000A - Ref.:OPMSTA200910-GB_06
ENGLISH
1. WARRANTY CERTIFICATE 2
2. SAFETY PROCEDURES
3
2. 1. Foreword
3
2. 2. Precautions
3
2. 3. electrical risk
3
2. 4. risk oF Power cut
3
3. THE ROLE OF STATYS 4
4. OPERATING PRINCIPLE
4
5. OPERATING MODES
5
5. 1. Manual transFer
5
5. 2. autoMatic transFer
5
5. 3. autoMatic restart Function
6
5. 4. overload oPeration
6
6. FUNCTIONAL DIAGRAMS 7
7. MIMIC PANEL
8
7. 1. lcd and leds
8
7. 2. GraPhic MiMic Panel adicoM
18
8. COMMISSIONING 34
8. 1. start conditions
34
8. 2. Power-uP oF statYs
34
8. 3. selectinG the PreFerred source
34
8. 4. load suPPlY
34
8. 5. transFer onto “Maintenance bYPass”
34
8. 6. “Maintenance bYPass” return
35
9. COMMUNICATION INTERFACE 35
10. ADVANCED DIAGNOSTICS AND PARAMETERS
35
INDEX

socomec STATYS series Specifications

General

Type	Automatic Transfer Switch (ATS)
Frequency	50/60 Hz
Number of Poles	3, 4
Protection	Short Circuit
Humidity	95% RH non-condensing
Standards	IEC 60947-6-1, UL 1008
Applications	Data centers, Industrial
Technology	Static switch (Solid-state)
Operating Temperature	-25°C to +60°C
