Voltage Range (% of Base Voltage) Maximum Clearing Time (Sec)
V < 50% 0.16
50 % < V < 88% 2.00
110% < V < 120% 1.00
V > 120 % 0.16
Frequency Range (Hz) Maximum Clearing Time (Sec)
> 60.5 0.16
< 59.3 (Hawaii – 57) 0.16
Recommended OCPD Size per Grid
Inverter
Maximum Output
Current (A)
Minimum Fuse Rating
(A)
Maximum Fuse
Rating (A)
SE3800H-US 16 20 50
SE5000H-US
21
30 50
SE6000H-US
25 35
50
SE7600H-US 32 40 50
SE11400H-US
47.5 60
80
EV Charger and EV Charger Cable Specifications
OUTPUT — AC
Charging Level
AC Level 2
Connection to the SolarEdge monitoring
platform is required for first EV charging
Rated AC Power Output (Grid &
PV)
9600 W
Nominal AC Output Voltage 240 Vac
Nominal AC Frequency 60 Hz
Maximum Continuous Output
Current @240V
(Grid & PV)
40 Aac
Ground Fault Detection
Threshold
5 mA
ADDITIONAL FEATURES
EV Charger Status LEDs, Fault
Indicator
Yes
EV Charger Unplugging
Detection
Yes, current termination according to SAE
J1772
Technical Specifications - EV Charging Single Phase Inverter (North America)
87
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
