4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-5. MOUNTED PARTS LOCATION
no mark : side A
* mark : side B
CD-408 BOARD
CD-408
C301 C-3
C302 B-2
C303 B-3
C304 C-3
C305 C-2
C306 B-2
C307 B-2
C309 B-3
C310 B-3
CN301 B-3
CN302 A-3
CN303 A-3
D301 B-2
D302 A-3
FB301 C-3
FB302 A-3
FB303 A-3
FB304 A-3
FB305 A-3
IC301 B-2
L301 B-2
L302 A-2
Q301 B-2
Q302 B-3
Q303 A-2
R306 B-2
R307 B-2
R308 B-2
R309 B-2
R310 B-3
R311 B-3
R312 C-3
R313 A-2
R314 A-2
R315 A-3
R316 A-3
R317 C-3
R318 C-3
R319 C-3
R320 C-3
TH301 B-2

Sony CYBER-SHOT DSC-F717 Specifications

General

Sensor Type	CCD
Effective Pixels	5.0 megapixels
Optical Zoom	5x
Digital Zoom	2x
Aperture Range	f/2.0 - f/2.4
LCD Screen Size	1.8 inches
LCD Screen Resolution	123, 000 pixels
Viewfinder	Electronic
Image Sensor Size	2/3 inch
Lens Type	Carl Zeiss Vario-Sonnar
Camera Type	Digital Still Camera
ISO Sensitivity	100, 200, 400
Storage Media	Memory Stick
Battery Type	NP-FM50
Focal Length	9.7 - 48.5 mm
Focus Range	2 cm (macro)
