5-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Ref. No. Part No. Description
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
DSC-F717
5-8
AJ-005 AL-013 BT-015
A-7078-475-A AJ-005 BOARD, COMPLETE
***********************
< DIODE >
D151 8-719-073-01 DIODE MA111-(K8).S0
D153 8-719-075-15 DIODE MAZT082H08S0
D154 8-719-075-15 DIODE MAZT082H08S0
< FERRITE BEAD >
FB151 1-469-179-21 FERRITE 0uH
< JACK >
J151 1-794-666-31 PIN JACK (4 POLES) (ACC)
A-7078-483-A AL-013 BOARD, COMPLETE
***********************
< BATTERY >
BT201 1-756-191-21 BATTERY, LITHIUM (SECONDARY)
< DIODE >
D204 8-719-073-01 DIODE MA111-(K8).S0
< FERRITE BEAD >
FB202 1-500-444-11 FERRITE 0uH
< JACK >
J201 1-569-950-31 JACK (SMALL TYPE) (A/V OUT (MONO))
< RESISTOR >
R201 1-216-821-11 METAL CHIP 1K 5% 1/16W
R202 1-216-864-11 METAL CHIP 0 5% 1/16W
R203 1-216-295-91 SHORT CHIP 0
R204 1-216-864-11 METAL CHIP 0 5% 1/16W
A-7078-478-A BT-015 BOARD, COMPLETE
***********************
< CAPACITOR >
C403 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C404 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C406 1-135-957-91 TANTAL. CHIP 10uF 20% 16V
C407 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C408 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C409 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C410 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C411 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C412 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C413 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
0 C414 1-165-806-11 ELECT 120uF 310V
0 C415 1-165-806-11 ELECT 120uF 310V
C416 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN401 1-691-550-11 PIN, CONNECTOR (1.5MM)(SMD) 3P
CN402 1-691-550-51 PIN, CONNECTOR (1.5MM)(SMD) 3P
CN403 1-793-027-21 CONNECTOR 14P
CN404 1-815-494-11 PIN, CONNECTOR 2P
< DIODE >
D401 8-719-075-15 DIODE MAZT082H08S0
D402 8-719-158-49 DIODE RD12SB2
D403 8-719-027-76 DIODE 1SS357-TPH3
D404 8-719-073-01 DIODE MA111-(K8).S0
0 D405 6-500-237-01 DIODE HAU160C030TP
< FUSE >
0 F401 1-576-406-21 FUSE, MICRO (1608) (1.4A/32V)
0 F402 1-576-406-21 FUSE, MICRO (1608) (1.4A/32V)
0 F403 1-576-406-21 FUSE, MICRO (1608) (1.4A/32V)
0 F404 1-576-406-21 FUSE, MICRO (1608) (1.4A/32V)
0 F405 1-576-406-21 FUSE, MICRO (1608) (1.4A/32V)
< FERRITE BEAD >
FB401 1-414-228-11 FERRITE 0uH
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canaidan model
HK : Hong Kong model
JE : Tourist model
J : Japanese model
To Next Page
