2-7E
DCR-HC40/HC40E
2. DISASSEMBLY
2. DISASSEMBLY
2-4. FLEXIBLE BOARDS LOCATION
The flexible boards contained in the lens block is not shown.
FP-831
FP-836
FP-830
FP-834
FFC-036
FP-835
FP-833
CONTROL KEY BLOCK
(SS6300)
CONTROL KEY BLOC
K
(CF6300)
CONTROL KEY BLOC
K
(SB6300)
FP-832
FP-828
