5-14
DCR-HC40/HC40E
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
CD-490 FP-836
A-7112-117-A CD-490 BOARD, COMPLETE
***********************
(IC201 is not included in this COMPLETE board)
< CAPACITOR >
C202 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C204 1-113-987-11 TANTAL. CHIP 4.7uF 20.00% 25V
C205 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C207 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C208 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C209 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C210 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C213 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C214 1-135-259-11 TANTAL. CHIP 10uF 20.00% 6.3V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C218 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V
C219 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< CONNECTOR >
CN201 1-818-087-31 CONNECTOR, FFC/FPC (LIF) 26P
< FERRITE BEAD >
FB201 1-414-760-21 FERRITE 0UH
< IC >
IC201 A-7112-341-A CCD BLOCK ASSY (1M) (CCD IMAGER)
(IC201 is not included in this COMPLETE board)
IC202 6-701-755-01 IC AD80017AJRURL
< COIL >
L201 1-400-588-11 INDUCTOR 0uH
L202 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q201 6-550-119-01 TRANSISTOR DTC144EMT2L
Q202 8-729-055-21 TRANSISTOR 2SC5096-O/R(TE85L)
< RESISTOR >
R201 1-218-990-11 SHORT CHIP 0
R203 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R204 1-218-965-11 RES-CHIP 10K 5% 1/16W
R205 1-218-953-11 RES-CHIP 1K 5% 1/16W
R206 1-218-966-11 RES-CHIP 12K 5% 1/16W
************************************************************
A-7112-125-A FP-836 BOARD, COMPLETE
**********************
< SWITCH >
S101 1-786-179-31 SWITCH, PUSH (1KEY) (PANEL REVERSE)
************************************************************
A-7112-122-A IR-051 BOARD, COMPLETE
**********************
< CAPACITOR >
C601 1-164-939-11 CERAMIC CHIP 0.0022uF 10.00% 50V
C602 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN601 1-778-507-21 PIN, CONNECTOR (PC BOARD) 4P
CN602 1-766-346-21 CONNECTOR, FFC/FPC 16P
< DIODE >
D601 6-500-512-01 DIODE CL-330IRS-X-TU
D602 6-500-506-01 DIODE TLRMV1021(T15SOY,F)
D604 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB601 1-500-444-11 FERRITE 0uH
FB602 1-500-444-11 FERRITE 0uH
< IC >
IC601 8-742-221-00 IC SBX3055-01
< JACK >
J601 1-691-737-41 JACK (SMALL TYPE) (MIC (PLUG IN POWER))
< RESISTOR >
R601 1-218-956-11 RES-CHIP 1.8K 5% 1/16W
R604 1-218-937-11 RES-CHIP 47 5% 1/16W
< SWITCH >
S601 1-786-148-11 SWITCH, PUSH (1 KEY) (LENS COVER OPEN/CLOSE)
< VARISTOR >
VDR601 1-801-862-11 VARISTOR, CHIP (1608)
VDR602 1-801-862-11 VARISTOR, CHIP (1608)
************************************************************
A-7112-123-A JK-260 BOARD, COMPLETE
**********************
< CONNECTOR >
CN701 1-815-794-21 CONNECTOR (MULTIPLE) (AV IN/OUT)
CN702 1-794-962-11 CONNECTOR, SQUARE TYPE(USB 5P) (USB)
CN703 1-794-276-11 CONNECTOR, SQUARE TYPE 4P ( DV)
CN704 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
< DIODE >
D702 6-500-750-01 DIODE NSAD500H-T1-A
D703 8-719-078-02 DIODE 1SS357(T3SONY1)
< JACK >
J701 1-793-995-11 JACK, SUPER SMALL TYPE ( LANC)
< LINE FILTER >
LF701 1-456-583-11 INDUCTOR 0uH
Be sure to read “Precautions upon replacing CCD imager”
on page 4-5 when changing the CCD imager.
4-6
IR-051 JK-260
