5-16E
DCR-HC40/HC40E
< TRANSISTOR >
Q601 8-729-427-42 TRANSISTOR XP4211-TXE
Q602 8-729-427-12 TRANSISTOR XP4111-TXE
Q603 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q604 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q605 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q606 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q607 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q608 6-550-119-01 TRANSISTOR DTC144EMT2L
Q609 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q610 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R606 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R607 1-218-989-11 RES-CHIP 1M 5% 1/16W
R608 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R609 1-218-975-11 RES-CHIP 68K 5% 1/16W
R610 1-218-990-11 SHORT CHIP 0
R611 1-218-977-11 RES-CHIP 100K 5% 1/16W
R613 1-220-206-11 METAL CHIP 91K 0.5% 1/16W
R614 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R615 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R616 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R617 1-218-953-11 RES-CHIP 1K 5% 1/16W
R619 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R620 1-218-969-11 RES-CHIP 22K 5% 1/16W
R623 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R624 1-218-973-11 RES-CHIP 47K 5% 1/16W
R625 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R627 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R633 1-218-990-11 SHORT CHIP 0
R634 1-218-989-11 RES-CHIP 1M 5% 1/16W
R635 1-218-949-11 RES-CHIP 470 5% 1/16W
R636 1-218-953-11 RES-CHIP 1K 5% 1/16W
R637 1-218-978-11 RES-CHIP 120K 5% 1/16W
R638 1-216-864-11 METAL CHIP 0 5% 1/16W
R639 1-216-864-11 METAL CHIP 0 5% 1/16W
R640 1-218-949-11 RES-CHIP 470 5% 1/16W
R641 1-218-949-11 RES-CHIP 470 5% 1/16W
R642 1-218-973-11 RES-CHIP 47K 5% 1/16W
R643 1-218-973-11 RES-CHIP 47K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-234-369-21 RES, NETWORK 10X4 (1005)
************************************************************
A-7112-151-A SE-141 BOARD, COMPLETE
**********************
< CAPACITOR >
C401 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C402 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C403 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C405 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C406 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C408 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C409 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C410 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C411 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C412 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C413 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C414 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C416 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN401 1-766-336-21 CONNECTOR, FFC/FPC 6P
< FERRITE BEAD >
FB401 1-469-179-21 FERRITE 0uH
FB402 1-469-179-21 FERRITE 0uH
FB403 1-469-179-21 FERRITE 0uH
FB404 1-469-179-21 FERRITE 0uH
< IC >
IC401 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L401 1-400-588-11 INDUCTOR 0uH
< RESISTOR >
R402 1-218-989-11 RES-CHIP 1M 5% 1/16W
R403 1-218-965-11 RES-CHIP 10K 5% 1/16W
R404 1-218-965-11 RES-CHIP 10K 5% 1/16W
R405 1-218-989-11 RES-CHIP 1M 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB401 1-234-379-21 RES, NETWORK 22KX4 (1005)
< SENSOR >
SE401 1-476-807-41 SENSOR, ANGULAR VELOCITY (PITCH)
SE402 1-476-807-31 SENSOR, ANGULAR VELOCITY (YAW)
************************************************************
VC-352 BOARD, COMPLETE
**********************
Electrical parts list of the VC-352 board
are not shown.
Pages from 5-17 to 5-25 are not shown.
PD-213 SE-141 VC-352
