75
DSR-200 U/C 3-858-622-22(1). E
Advanced operations
Audio dubbing
If you recorded in Fs 32k (12 bit) recording mode, you can add stereo narration or music
to the recording.
Making connections
To use additional audio line in [a]
Connect the LINE OUT jacks of a audio source to the rear AUDIO IN jacks of the digital
camcorder using an audio connecting cord with the XLR connector (not supplied) and
then set LINE/MIC to LINE.
To use an additional microphone
• Use the built-in microphone [b] or connect an external microphone (not supplied) [c]
to the MIC (PLUG IN POWER) jack, then set LINE/MIC to MIC FRONT.
• Use an external microphone (not supplied) with the XLR connector [d], connect the
rear AUDIO IN jack of the digital camcorder, then set LINE/MIC to MIC REAR.
[d]
[c]
[b]
[a]
: Signal flow
Audio source
MIC
MIC
To Next Page
