15
HCD-SB100/SB200
Ver. 1.1
3-5. DVD BOARD
1
two screws
2
cover
6
four screws
5
connector
(CN903)
7
connector
(PDA02)
8
connector
(PDA03)
3
w
ire (flat type)
23p (PDM01)
4
w
ire (flat type)
11p (PDM02)
9
DVD board
