80
HCD-SB100/SB200
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
•Abbreviation
AUS: Australian model
CND : Canadian model
EA : Saudi Arabia model
EE : East European model
RU : Russian model
SP : Singapore model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
When indicating parts by reference number,
please include the board name.
9-885-071-11 AMP BOARD ASSY (200:UK,AEP,EE)
9-885-071-12 AMP BOARD ASSY (200:RU)
9-885-071-13 AMP BOARD ASSY (200:SP,AUS)
9-885-069-52 AMP BOARD ASSY (US,CND)
9-885-069-51 AMP BOARD ASSY (AUS,EA,SP)
9-885-069-33 AMP BOARD ASSY (100:UK,AEP,EE)
9-885-069-50 AMP BOARD ASSY (RU)
*****************************
< DIODE >
D101 9-885-073-19 DIODE RECTIFIERS
D102 9-885-073-19 DIODE RECTIFIERS
D103 9-885-073-19 DIODE RECTIFIERS
D104 9-885-073-19 DIODE RECTIFIERS
D105 9-885-073-19 DIODE RECTIFIERS
D111 8-719-991-34 DIODE SWITCHING (US,CND)
D114 8-719-991-34 DIODE SWITCHING (US,CND)
D115 8-719-991-34 DIODE SWITCHING (US,CND)
D116 8-719-991-34 DIODE SWITCHING (AEP,UK,EE)
D117 8-719-991-34 DIODE SWITCHING (AEP,UK,RU,EE)
D119 8-719-991-34 DIODE SWITCHING (200)
D300 9-885-073-19 DIODE RECTIFIERS
D301 8-719-991-34 DIODE SWITCHING
D600 8-719-991-34 DIODE SWITCHING (AEP,UK,RU,EE)
D800 8-719-991-34 DIODE SWITCHING (200)
D801 8-719-991-34 DIODE SWITCHING (200)
D981 8-719-991-34 DIODE SWITCHING
< FILTER >
FB508 1-795-645-11 FILTER, CERAMIC (EMI)
FB509 1-795-645-11 FILTER, CERAMIC (EMI)
FB601 1-795-645-11 FILTER, CERAMIC (EMI)
FB602 1-795-645-11 FILTER, CERAMIC (EMI)
FB603 1-795-645-11 FILTER, CERAMIC (EMI)(US,CND,SP,EA,AUS)
FB604 1-795-645-11 FILTER, CERAMIC (EMI)(US,CND,SP,EA,AUS)
FB605 1-795-645-11 FILTER, CERAMIC (EMI)(US,CND,SP,EA,AUS)
FB606 1-795-645-11 FILTER, CERAMIC (EMI)
FB607 1-795-645-11 FILTER, CERAMIC (EMI)
FB612 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
FB613 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
FB614 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
FB615 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
FB616 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
FB617 1-795-645-11 FILTER, CERAMIC (EMI)(AEP,UK.RU,EE)
< IC >
IC101 9-885-073-39 IC LC876848C-54C7
IC202 9-885-073-36 IC CS5331A-KSR
IC301 9-885-073-48 IC PS9818
IC501 8-759-656-83 IC NJM4580M 8
IC502 8-759-656-83 IC NJM4580M 8
IC601 9-885-073-54 IC BU4052BCFV
IC710 9-885-054-79 IC STA505-5C (100)
IC710 9-885-073-52 IC STA-508 STM (200)
IC730 9-885-054-79 IC STA505-5C (100)
IC730 9-885-073-52 IC STA-508 STM (200)
IC750 9-885-073-51 IC STA501 STM (100)
IC750 9-885-073-52 IC STA-508 STM (200)
IC770 9-885-054-79 IC STA505-5C (100)
IC770 9-885-073-52 IC STA-508 STM (200)
< JACK >
JK601 9-885-073-89 JACK,RCA (MONITOR OUT,VIDEO)
(AEP,UK,RU,EE)
JK601 9-885-073-90 JACK,RCA (COMPONENT VIDEO OUT)
(US,CND,SP,EA,AUS)
JK602 9-885-073-91 JACK,SCART (EURO AV OUTPUT (TO TV))
(AEP,UK,RU,EE)
< FILTER/COIL >
L102 1-795-645-11 FILTER, CERAMIC (EMI)
L103 1-795-645-11 FILTER, CERAMIC (EMI)
L104 1-795-645-11 FILTER, CERAMIC (EMI)
L105 1-795-645-11 FILTER, CERAMIC (EMI)
L106 1-795-645-11 FILTER, CERAMIC (EMI)
L200 1-795-645-11 FILTER, CERAMIC (EMI)
L207 9-885-073-57 INDUCTOR,AXIAL LEAD (200)
L208 9-885-073-57 INDUCTOR,AXIAL LEAD (200)
L300 1-795-645-11 FILTER, CERAMIC (EMI)
L301 1-795-645-11 FILTER, CERAMIC (EMI)
L303 1-795-645-11 FILTER, CERAMIC (EMI)
L304 1-795-645-11 FILTER, CERAMIC (EMI)
L305 1-795-645-11 FILTER, CERAMIC (EMI)
L309 1-795-645-11 FILTER, CERAMIC (EMI)
L710 1-795-645-11 FILTER, CERAMIC (EMI)
L730 1-795-645-11 FILTER, CERAMIC (EMI)
L750 1-795-645-11 FILTER, CERAMIC (EMI)
L770 1-795-645-11 FILTER, CERAMIC (EMI)
Ver. 1.4
