HCD-SB100/SB200
65
HCD-SB100/SB200
Ver. 1.1
7-18. PRINTED WIRING BOARD – POWER SECTION (SB100) – • See page 45 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D901 E-7
D902 E-7
D903 E-7
D911 E-3
D912 E-3
D921 C-8
D922 C-8
D923 C-7
D924 D-7
D926 D-7
D927 D-7
D928 B-4
D929 A-6
D932 D-5
D933 C-5
D941 D-6
IC901 E-7
IC902 E-6
IC921 B-7
IC922 B-6
IC923 C-6
IC924 B-7
IC941 D-8
IC942 C-5
Q910 F-7
Q921 D-5
Q922 D-5
ZD911 E-5
ZD921 C-5
IC902
IC901
IC942
IC923
IC921
IC922
IC924
IC941
E
AMP BOARD
(SB100)
PN901
(Page 50)
F
AMP BOARD
(SB100)
PN902
(Page 50)
G
DVD BOARD
PDA01
(Page 59)
TRANSFORMER
TRANSFORMER
4
1
1
4
41
1
3
1
10
1
3
1
4
5
8
E
1
3
E
E
AC IN
12
A
B
C
D
E
F
34567
8
[POWER BOARD] (SB100)
