Sony HDR-UX1 User Manual

42
Recording the images (Continued)
Still images are recorded on the “Memory Stick Duo.”
Slide the POWER switch in the direction of the arrow to light up
the (Still) lamp.
Press PHOTO lightly to adjust the focus A, then press it fully B.
A shutter sound is heard. When disappears, the image has been recorded.
Recording still images
To switch to the still image recording mode using the (HOME) button
1 Press (HOME) C (or D) when the power of the camcorder is on.
2 Touch the (CAMERA) category on the HOME MENU.
3 Touch [PHOTO].
Slide the POWER switch in the direction of the arrow
while pressing the green button only when the POWER
switch is in the OFF (CHG) position.
Flashing bLights up
Beep Click

Sony HDR-UX1 Specifications

Imaging and Video

imaging device	1/3" 2100K Gross Pixels
video actual	1076K Pixels (4:3), 1434K Pixels (16:9)
still actual	1991K Pixels (4:3), 1493K Pixels (16:9)
video recording system	MPEG4/AVC (H.264)
video signal system	NTSC color

Audio

recording system	Dolby® Digital 5.1
built-in microphone	5.1 Channel
headphone jack	Stereo Mini

Optics and Lens

35mm equivalent	41.3-485mm (16:9), 50.5-594mm (4:3)
aperture	f1.8-2.9
focal distance	5.1-51mm
optical zoom	10X
digital zoom	80X

Display

lcd size	3.5" (211K Pixels)
viewfinder	Color, 123K Pixels (16:9)

Power

power consumption	5.0W/5.2W (VF/LCD)
battery type	InfoLithium® (NP-FM50)
power requirements	7.2V Battery/8.4V AC Adaptor

Inputs and Outputs

digital audio/video input	Yes (via USB)
digital audio/video output	Yes (via USB)
component video output	Yes
hdmi connection output	Yes
usb ports	Yes; 2.0 High Speed Compliant

Weight and Dimensions

weight	1 lb, 10oz
measurements	3" x 3 5/8" x 6 1/2"
