JP4
JP2
Component side
Ref No. Setting Factory setting
JP2 OPEN/SHORT OPEN
JP4 1-2/2-3 1-2
3-5-3. Description of Onboard Sensor
MB board
System Temp #1
Sensor
System Temp #2
Sensor
System FAN
Connector
Component side
HVO-500MD/HVO-550MD
3-8
