Sony HVO-500MD Service Manual

6-6. DIMM
Preparation
1. Remove the top cover. (Refer to “6-2. Top Cover”)
2. Remove the DVD drive assembly. (HVO-550MD only) (Refer to “6-5. DVD Drive (HVO-550MD Only)”)
Procedure
1. Open the two levers to detach the DIMM.
Lever Lever
DIMM
2. Install the removed parts by reversing the steps of removal.
Note
When installing the DIMM, make sure that the levers catch the groove of DIMM.
Lever
Lever
Note for installing
DIMM
HVO-500MD/HVO-550MD
6-9

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
