Additional Information
73
GB
••
BLUETOOTH devices connected with
this system must comply with the
BLUETOOTH specification prescribed
by the Bluetooth SIG, Inc., and must
be certified to comply. However, even
when a device complies with the
BLUETOOTH specification, there may
be cases where the characteristics or
specifications of the BLUETOOTH device
make it impossible to connect, or may
result in different control methods,
display or operation.
••
Noise may occur or the audio may
cut off depending on the BLUETOOTH
device connected with this system,
the communications environment, or
surrounding conditions.
Specifications
Speaker section
MHC-V82D
Speaker system:
5-way, Double Bass Reflex
Speaker unit:
Tweeter L/R Front: 50 mm, cone
type
Tweeter L/R Rear: 50 mm, cone
type
Midrange L/R (Upper): 100 mm,
cone type
Midrange L/R (Lower): 120 mm,
cone type
Woofer: 300 mm, cone type
MHC-V72D
Speaker system:
4-way, Double Bass Reflex
Speaker unit:
Tweeter L/R Front: 50 mm, cone
type
Tweeter L/R Rear: 50 mm, cone
type
Midrange L/R: 120 mm, cone type
Woofer: 300 mm, cone type
Inputs
AUDIO/PARTY CHAIN IN (TV) L/R:
Voltage 2 V, impedance
24kilohms
TV (ARC):
Supported audio signal:
2-channel Linear PCM
MIC1:
Sensitivity 1 mV, impedance
10kilohms
MIC2/GUITAR:
Sensitivity 1 mV, impedance
10kilohms (When guitar mode is
turned off.)
Sensitivity 200 mV, impedance
250 kilohms (When guitar mode is
turned on.)
Outputs
AUDIO/PARTY CHAIN OUT L/R:
Voltage 2 V, impedance 1kilohm
HDMI OUT (TV) ARC:
Supported audio signal:
2-channel Linear PCM (up to
48kHz), Dolby Digital
HDMI section
Connector:
Type A (19pin)
Disc player section
System:
Compact disc and digital audio
and video system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 μW
* This output is the value
measurement at a distance of
200 mm from the objective lens
surface on the Optical Pick-up
Block with 7 mm aperture.
Frequency response:
20Hz – 20kHz

Sony MHC-V72D Specifications

General

FM radio	Yes
Control type	Touch
Audio (L/R) in	1
Bluetooth profiles	A2DP, AVRCP, SPP
Playback disc types	CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW
Radio Frequency (RF) range	87.5 - 108 MHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Audio decoders	Dolby Digital
RMS rated power	- W
Audio formats supported	MP3
Power consumption (standby)	0.5 W
Speaker type	-
Woofer diameter	300 mm
Tweeter diameter	50 mm
Speaker placement	Floor, Tabletop/bookshelf
Audio output channels	- channels
Mid-range driver diameter	120 mm
Number of tweeter drivers	4
Number of mid-range drivers	2
Product color	Black
Recommended usage	Stage

Weight and Dimensions

Depth	427 mm
Width	370 mm
Height	930 mm
Weight	21600 g
