Page #20 background imageLoading...
Page #20 background image
NSX-24GT1/32GT1/40GT1/46GT1 15
DISASSEMBLY/PART NUMBER INFORMATION
1-8. ACCESSORIES AND PACKAGING
A-1783-121-A ACCESSORY ASSEMBLY
(NSX-24GT1 ONLY)
A-1783-117-A ACCESSORY ASSEMBLY
(NSX-32GT1 ONLY)
A-1783-124-A ACCESSORY ASSEMBLY
(NSX-40GT1 ONLY)
A-1783-127-A ACCESSORY ASSEMBLY
(NSX-46GT1 ONLY)
4-262-657-11 INSTRUCTION (WALL INSTALLATION)
(NSX-24GT1 ONLY)
4-197-994-12 INSTRUCTION MANUAL
* 4-197-996-11 SUPPLEMENT(TABLE-TOP STAND)
1-458-066-11 VIDEO CONTROLLER (AV MOUSE)
1-9. MISCELLANEOUS
! 1-838-261-11 AC POWER SUPPLY CORD WITH CONN
(NSX-24GT1 ONLY)
4-262-656-01 PLATE, VESA
(NSX-24GT1 ONLY)
! 1-837-644-12 POWER-SUPPLY CORD SET
(ALL EXCEPT NSX-24GT1 ONLY)
4-198-175-01 THERMAL PAD (NAND) (24)
(NSX-24GT1 ONLY)
4-198-172-01 THERMAL PAD (AL PLATE)
4-198-173-01 THERMAL PAD (AL PLATE) (THIN)
(NSX-40GT1 ONLY)
4-198-174-01 THERMAL PAD (NAND)
(ALL EXCEPT NSX-24GT1 ONLY)
1-10. REMOTE COMMANDER
1-489-213-12 REMOTE COMMANDER (NSG-MR1)

Table of Contents

Other manuals for Sony NSX-40GT1

Preview: Help Guide
Help Guide103 pages
Preview: Specifications
Specifications2 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony NSX-40GT1 and is the answer not in the manual?

Sony NSX-40GT1 Specifications

Power IconPower
power requirements voltageAC 120V
power requirements frequency60Hz
power consumption in operation122 W
power consumption in standby0.5 W
power consumption in download acquisition mode34 Wh/day
Display IconDisplay
aspect ratio16:9
backlight typeEdge LED
display deviceLCD
display resolution1920 x 1080p (Full HD)
screen size40 inches
viewing angle right/left178(89/89)
viewing angle up/down178(89/89)
Audio IconAudio
audio power output20W (10W x 2)
audio dac48kHz/24bit
speakers total2
Inputs and Outputs IconInputs and Outputs
ac power1 (Rear)
composite video input1 (Rear)
component video input1 (Rear)
hdmi connections input4 (2 Rear/ 2 Side)
analog audio input1 (Rear)
analog audio output1 (Headphone)
digital audio optical output1 (Rear)
usb 2.04 (Side)
ethernet connections10BASE-T/100BASE-TX/1000BASE-T (Rear)
Weight and Dimensions IconWeight and Dimensions
dimensions without pedestal37 5/8 x 23 1/8 x 2 1/8 inches
dimensions with pedestal37 5/8 x 24 3/8 x 11 3/4 inches
packaging dimensions41 1/8 x 27 x 6 3/4 inches
weight without pedestal37.7 lbs
weight with pedestal41.5 lbs
