Sony NSX-40GT1 Service Manual

NSX-24GT1/32GT1/40GT1/46GT1 i
TABLE OF CONTENTS
Specications..................................................................................................................................................................................1
Warnings and Cautions ..................................................................................................................................................................3
Safety-Related Warning ..................................................................................................................................................................5
Safety Check-Out ............................................................................................................................................................................6
SEC 1. Disassembly/Part Number Information ............................................................................................................................8
1-1. Table-Top Stand Assembly Removal ...............................................................................................................................8
1-2. Rear Cover, Speakers, Antennas, RF Module and HA Board Removal ..........................................................................9
1-2-1. NSX-24GT1 Only ......................................................................................................................................................................... 9
1-2-2. NSX-32GT1/40GT1/46GT1 Only ............................................................................................................................................... 10
1-3. G/GE6/GE7A/GE7B (Power) Boards, BA Board, M Board, Wireless LAN Card and LCD Panel Removal ..................11
1-3-1. NSX-24GT1 Only ........................................................................................................................................................................11
1-3-2. NSX-32GT1/40GT1/46GT1 Only ............................................................................................................................................... 12
1-4. Cleaning the LCD Panel ................................................................................................................................................13
1-5. Screw Legend................................................................................................................................................................13
1-6. Connectors (NSX-24GT1 Only) .....................................................................................................................................14
1-7. Connectors (NSX-32GT1/40GT1/46GT1 Only) .............................................................................................................14
1-8. Accessories and Packaging ..........................................................................................................................................15
1-9. Miscellaneous ................................................................................................................................................................15
1-10. Remote Commander .....................................................................................................................................................15
1-11. Wire Dressing ................................................................................................................................................................16
1-11-1.Wire Dressing (NSX-24GT1 Only) .............................................................................................................................................. 16
1-11-2.Wire Dressing (NSX-32GT1/40GT1/46GT1 Only) ...................................................................................................................... 16

Sony NSX-40GT1 Specifications

Power

power requirements voltage	AC 120V
power requirements frequency	60Hz
power consumption in operation	122 W
power consumption in standby	0.5 W
power consumption in download acquisition mode	34 Wh/day

Display

aspect ratio	16:9
backlight type	Edge LED
display device	LCD
display resolution	1920 x 1080p (Full HD)
screen size	40 inches
viewing angle right/left	178(89/89)
viewing angle up/down	178(89/89)

Audio

audio power output	20W (10W x 2)
audio dac	48kHz/24bit
speakers total	2

Inputs and Outputs

ac power	1 (Rear)
composite video input	1 (Rear)
component video input	1 (Rear)
hdmi connections input	4 (2 Rear/ 2 Side)
analog audio input	1 (Rear)
analog audio output	1 (Headphone)
digital audio optical output	1 (Rear)
usb 2.0	4 (Side)
ethernet connections	10BASE-T/100BASE-TX/1000BASE-T (Rear)

Weight and Dimensions

dimensions without pedestal	37 5/8 x 23 1/8 x 2 1/8 inches
dimensions with pedestal	37 5/8 x 24 3/8 x 11 3/4 inches
packaging dimensions	41 1/8 x 27 x 6 3/4 inches
weight without pedestal	37.7 lbs
weight with pedestal	41.5 lbs
