Sony NSX-40GT1 Service Manual

NSX-24GT1/32GT1/40GT1/46GT1 1
SPECIFICATIONS
HDMI, the HDMI Logo, and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing
LLC in the United States and other
countries.
Fergason Patent Properties, LLC:
U.S. Patent No. 5,717,422
U.S. Patent No. 6,816,141
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
In the United States, TV Guide and TV
Guide On Screen are registered
trademarks of TV Guide Entertainment
Group, Inc. and/or its subsidiaries or
aliates, and are used under a license by
Gemstar-TV Guide International, Inc. and/
or its subsidiaries. In Canada, TV Guide is
a registered mark of Transcontinental Inc.,
and is used under a license by Gemstar-TV
Guide International, Inc. and/or its
subsidiaries.
The TV Guide On Screen system is
manufactured under license from
Gemstar-TV Guide International, Inc. and/
or its subsidiaries.
The TV Guide On Screen system is
protected by one or more of the following
United States
patents 6,498,895;
6,850,693; 6,396,546; 5,940,073;
6,239,794 to Gemstar-TV Guide
International, Inc. and/or its subsidiaries.
Gemstar-TV Guide International, Inc. and/
or its related aliates are not in any way
liable for the accuracy or availability of the
program schedule information or other
data in the TV Guide On Screen system
and cannot guarantee service availability
in your area. In no event shall Gemstar-TV
Guide International, Inc. and/or its related
aliates be liable for any damages in
connection with the accuracy or availability
of the program schedule information or
other data in the TV Guide On Screen
system.
Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
This product contains software which is
licensed by Fluendo
(http://www.uendo.com).
Your TV is ENERGY
STAR
®
qualied in the
"Home" mode
(NSX-32GT1/NSX-40GT1/
NSX-46GT1).
It meets strict energy
eciency guidelines set by the U.S.
Environmental Protection Agency and
Department of Energy. ENERGY STAR is a
joint program of these government
agencies, designed to promote energy
ecient products and practices.
Changes to certain features, settings, and
functionalities of this TV (i.e. TV Guide,
Picture/Sound, Light Sensor, Power
Savings) can increase or change the
power consumption.
Depending upon such changed settings,
the power consumption may exceed the
limits required for the ENERGY STAR
qualication in the "Home" mode.
Licensing Information
Model Name NSX- 46GT1 40GT1 32GT1 24GT1
System
Television system NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not include Cable CARD functionality)
Channel coverage Analog terrestrial: 2-69 / Digital terrestrial: 2-69
Analog Cable: 1-135 / Digital Cable: 1-135
lenaP )yalpsiD latsyrC diuqiL( DCLmetsys lenaP
W5 + W5W01 + W01tuptuo rekaepS
Input/Output jacks
CABLE/ANTENNA 75-ohm external terminal for RF inputs
OIDUA / OEDIVNI OEDIV
COMPONENT IN YPBPR (Component Video)/Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
HDMI IN 1/2/3/4 HDMI: Video:480i, 480p, 720p, 1080i, 1080p, 1080/24p
Audio: Two channel linear PCM 32, 44.1 and 48KHz, 16, 20 and 24bits, Dolby Digital
kcaj senohpdaeHENOHPDAEH
DIGITAL AUDIO OUT (OPTICAL) PCM/Dolby Digital optical signal
eht no gnidneped reffid yam deeps noitcennoC( rotcennoc T-ESAB0001/XT-ESAB001/T-ESAB01NAL
network environment. 10BASE-T/100BASE-TX/1000BASE-Tconnection rate and communication
quality are not guaranteed for this TV.)
*A epyT kcaj BSUBSU
1
)elbac retsalB RI eht gnitcennoc roF( kcaj iniMretsalB RI
Power and others
Power requirements 120 V AC, 60 Hz
Power consumption
W48W58W221W741esu ni
in DAM*
2
d/hW72d/hW43d/hW65
W5.0 naht sselybdnats ni
Screen size
(inches measured diagonally)
46 inches 40 inches 31.5 inches (32 class) 23.5 inches (24 class)
Display resolution 1,920 dots (horizontal) x 1,080 (vertical)
Speaker
Full range with speaker (mm) 45 × 130 45 × 130 45 × 130 34 × 105
(inches) 1
13
/16 × 5
1
/8 1
13
/16 × 5
1
/8 1
13
/16 × 5
1
/8 1
3
/8 × 4
1
/4
Dimensions
with stand (mm) 1,087 × 694 × 298 954 × 619 × 298 766 × 511 × 194 571 × 381 × 190
(inches) 42
7
/8 × 27
3
/8 × 11
3
/4 37
5
/8 × 24
3
/8 × 11
3
/4 30
1
/4 × 20
1
/8 × 7
3
/4 22
1
/2 × 15 × 7
1
/2
without stand (mm) 1,087 × 661 × 54 954 × 586 × 53 766 × 481 × 56 571 × 353 × 71
(inches) 42
7
/8 × 26
1
/8 × 2
1
/4 37
5
/8 × 23
1
/8 × 2
1
/8 30
1
/4 × 19 × 2
1
/4 22
1
/2 × 14 × 2
7
/8
wall-mount hole pattern
(mm)
300 × 300 300 × 300 200 × 200 100 ×100
wall-mount screw size
(mm)
M6 × 16 M6 × 16 M6 × 16 M4 × 12
Mass
with stand (kg)/(lb.) 22.7/50.1 18.8/41.5 13.2/29.2 10.1/22.3
without stand (kg)/(lb.) 21/46.4 17.1/37.7 11.8/26.1 8.7/19.2
*1
For details on USB devices that can be connected to the TV, see "Help Guide" (http://esupport.sony.com/internettv/helpguide).
*2
Download Acquisition Mode (DAM) is used for collecting data for TV Guide On Screen.

Sony NSX-40GT1 Specifications

Power

power requirements voltage	AC 120V
power requirements frequency	60Hz
power consumption in operation	122 W
power consumption in standby	0.5 W
power consumption in download acquisition mode	34 Wh/day

Display

aspect ratio	16:9
backlight type	Edge LED
display device	LCD
display resolution	1920 x 1080p (Full HD)
screen size	40 inches
viewing angle right/left	178(89/89)
viewing angle up/down	178(89/89)

Audio

audio power output	20W (10W x 2)
audio dac	48kHz/24bit
speakers total	2

Inputs and Outputs

ac power	1 (Rear)
composite video input	1 (Rear)
component video input	1 (Rear)
hdmi connections input	4 (2 Rear/ 2 Side)
analog audio input	1 (Rear)
analog audio output	1 (Headphone)
digital audio optical output	1 (Rear)
usb 2.0	4 (Side)
ethernet connections	10BASE-T/100BASE-TX/1000BASE-T (Rear)

Weight and Dimensions

dimensions without pedestal	37 5/8 x 23 1/8 x 2 1/8 inches
dimensions with pedestal	37 5/8 x 24 3/8 x 11 3/4 inches
packaging dimensions	41 1/8 x 27 x 6 3/4 inches
weight without pedestal	37.7 lbs
weight with pedestal	41.5 lbs
