89
Additional Information
6 OPEN button (29, 37)
Opens the disc cover. The unit
does not work without
connecting the AC power
adapter or battery pack.
7 g (remote sensor) (27)
Accepts the remote control
signals.
8 Front panel display (36, 44)
Indicates the playing time, etc.
9 BUSY indicator
Lights up in orange while
loading the data of
ROM.
!º · (play) button (30, 38)
Plays back a disc.
!¡ ∏ (pause) button (31, 39)
Pauses playing back a disc.
!™ π (stop) button (30, 38, 53)
Stops playing back a disc.
!£ SCSI connector (half pitch pin
type 50 pins)
Connects the supplied SCSI PC
card when using this unit as the
DVD-ROM drive.
!¢ HOLD switch (59)
Prevents accidental pressing of
the buttons.
!∞ DVD MENU button (34)
Displays the DVD menu on the
TV screen to set or adjust t
he
menu items.
!§ Battery pack connector (72)
Connects the optional battery
pack.
!¶ TITLE button (33)
Displays the title menu on the
TV screen.
!• RETURN button (41, 64)
Returns to the preceding
selection screen, etc.
!ª DC IN 10V jack (26)
Connects the AC power adapter
(supplied).
@º S VIDEO OUT connector (25)
Connects to the S video input
connector on the TV.
@¡ A/V OUT connector (25, 68)
Connects to the audio/video
input connectors on the TV or
amplifier.
@™ ?/>/.///ENTER buttons
Select the items or settings.
@£ POWER button (29, 37)
Turns the power on and off the
unit.
(continued)
