Preparing the Audio Input System
44
Chapter 2 Preparations
8 Repeat steps 4 to 7 until the chart stays
in focus all the way from wide angle to
telephoto.
9 Tighten the F.f or F.B ring fixing
screws.
You can attach the ECM-680S stereo microphone
(not supplied) to the microphone holder of the
HDVF-20A viewfinder (not supplied).
1 Loosen the screw and open the
microphone holder clamp.
2 Place the microphone in the
microphone holder.
1 Place the microphone in the holder so
that “UP” is at the top.
2 Close the microphone holder.
3 Tighten the screw.
On how to perform this operation, refer to the
operation manual for the microphone.
Preparing the Audio
Input System
Connecting a microphone to the
MIC IN connector
1
2
Microphone holder clamp
1
23
To Next Page
