51
HT-X9000F/XF9000
SECTION 6
EXPLODED VIEWS
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference
number in the exploded views are not sup-
plied.
• Color Indication of Appearance Parts Ex-
ample:
KNOB, BALANCE (WHITE) . . . (RED)
Parts Color Cabinet’s Color
6-1. FOOT SECTION
front side
rear side
right side
left side
A
B
B
A
#1
1
not supplied
not supplied
top cabinet section
#1
#2
#2
#2
#2
#2
#2
#2
#2
#2
1
#2
#2
#2
#2
#2
#2
#2
#2
#2
1
1
2
bottom cabinet section
top side
#1
#2
#2
front side
rear side
#2
– Bottom view –
left side
right side
2
1
1
1
1
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
1 4-597-760-01 CUSHION FOOT
2 4-693-812-01 FOOT, RUBBER
#1 7-685-645-79 SCREW +BVTP 3X6 TYPE2 IT-3
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
