HCD-C770/C990
8-1. GENERAL SECTION
SECTION 8
EXPLODED VIEWS
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
•Abbreviation
AUS: Australian model
CND : Canadian model
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1 4-240-373-01 SIDE PANEL (L)
2 4-240-374-01 SIDE PANEL (R)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
1
2
#1
#1
#1
#1
#1
#1
mechanism deck
section-1
(CDM69-DVBU16)
front panel section-1
chassis section-1
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
