18
HCD-C770/C990
8 screw
(PTPWH2.6
× 8)
1 screw
(PTPWH2.6
× 8)
9 cam
(eject lock)
: Note
qs gear
(eject lock)
qd gear
(mode 1)
qg two claws
0 screw
(PTPWH2.6
× 8)
ql screw
(BVTP2.6
× 8)
3 screw
(BVTP2.6
× 8)
7 shaft
(shutter)
6 compression spring
(shutter)
4 two screws
(BVTP2.6
× 8)
5 base (shutter) block
2 lever shutter (A)
w; sensor board
qf screw
(PTPWH2.6
× 8)
qh rotary encoder
(S701)
qj claw
qk harness
qa cam
(BU U/D)
Note: Refer to assembly (Section 4).
1 screw
(PTPWH2.6
× 8)
3 screw
(PTPWH2.6
× 8)
7 screw
(PTPWH2.6
× 8)
9 screw
(PTPWH2.6
× 8)
qa screw
(PTPWH2.6
× 8)
qs cam (gear)
: Note
5 screw
(PTPWH2.6
× 8)
2 pulley
(mode deceleration)
4 gear
(mode 5)
8 gear (mode 3)
0 gear
(mode 2)
:Note
6 gear (mode 4)
Note: Refer to assembly (Section 4).
3-18. CAM (GEAR)
3-19. SENSOR BOARD
