120
HCD-C770/C990
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
A-4676-968-A AMP BOARD, COMPLETE (US, CND)
A-4730-644-A AMP BOARD, COMPLETE (AEP, AUS)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR/CHIP CONDUCTOR >
C101 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C102 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C103 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C104 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C105 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C106 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C111 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C112 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C113 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C114 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C115 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C116 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C121 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C122 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C123 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C124 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C125 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C126 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C131 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C132 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C133 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C134 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C135 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C136 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C141 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C142 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C143 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C144 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C145 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C146 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C147 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C148 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C149 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C150 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C151 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C152 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C161 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C162 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C163 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C164 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C165 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C166 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C167 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C168 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C169 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C170 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C171 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C172 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C181 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C182 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C190 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C191 1-126-193-21 ELECT 1uF 20% 50V
C192 1-216-295-00 CONDUCTOR, CHIP
C300 1-115-819-11 ELECT 2200uF 20% 35V
C301 1-126-153-11 ELECT 22uF 20% 6.3V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-136-157-00 FILM 0.022uF 5% 50V
C304 1-136-157-00 FILM 0.022uF 5% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-124-584-00 ELECT 100uF 20% 10V
C313 1-136-165-00 FILM 0.1uF 5% 50V
C316 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C317 1-126-948-11 ELECT 100uF 20% 35V
C318 1-104-665-11 ELECT 100uF 20% 10V
C319 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C320 1-124-584-00 ELECT 100uF 20% 10V
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-124-584-00 ELECT 100uF 20% 10V
C326 1-124-589-11 ELECT 47uF 20% 16V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C329 1-126-176-11 ELECT 220uF 20% 10V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
•Abbreviation
AUS: Australian model
CND: Canadian model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
