STR-DA3500ES
4-144-907-11(1)
Other Operations
The following options are available in each
menu. For details on navigating through
menus, see page 41.
Overview of the menus
Menu
[Display
window]
Parameters
[Display window]
Settings Initial
Setting
Auto Calibration
[<AUTO CAL>]
Auto Calibration start
[A.CAL START]
Calibration type
[CAL TYPE]
FULL FLAT, ENGINEER,
FRONT REF, OFF
FULL
FLAT
Position
[POSITION]
POS 3, POS 2, POS 1 POS 1
Naming Inputs
[NAME IN]
For details, see “Naming inputs”
(page 101).
Level Settings
[<LEVEL>]
Test tone
[TEST TONE]
OFF, FIX xxx
a)
, AUTO xxx
a)
OFF
Phase noise
[P. NOISE]
OFF, FL/FR, FL/SR, SL/FL, SB/SL,
SBL/SL, SBR/SBL, SR/SB, SR/SBR,
SR/SL, FR/SR, FR/SL, CNT/FR,
FL/CNT
OFF
Phase audio
[P. AUDIO]
OFF, FL/FR, FL/SR, SL/FL, SB/SL,
SBL/SL, SBR/SBL, SR/SB, SR/SBR,
SR/SL, FR/SR, FR/SL, CNT/FR,
FL/CNT
OFF
Front left speaker level
[FL LEVEL]
FL -10.0 dB to FL +10.0 dB
(0.5 dB step)
FL 0 dB
Front right speaker level
[FR LEVEL]
FR -10.0 dB to FR +10.0 dB
(0.5 dB step)
FR 0 dB
Center speaker level
[CNT LEVEL]
CNT -20.0 dB to CNT +10.0 dB
(0.5 dB step)
CNT 0 dB
Surround left speaker level
[SL LEVEL]
SL -20.0 dB to SL +10.0 dB
(0.5 dB step)
SL 0 dB
Surround right speaker level
[SR LEVEL]
SR -20.0 dB to SR +10.0 dB
(0.5 dB step)
SR 0 dB
Surround back speaker level
b)
[SB LEVEL]
SB -20.0 dB to SB +10.0 dB
(0.5 dB step)
SB 0 dB
Surround back left speaker level
c)
[SBL LEVEL]
SBL -20.0 dB to SBL +10.0 dB
(0.5 dB step)
SBL 0 dB
Surround back right speaker level
c)
[SBR LEVEL]
SBR -20.0 dB to SBR +10.0 dB
(0.5 dB step)
SBR 0 dB
Subwoofer level
[SW LEVEL]
SW -20.0 dB to SW +10.0 dB
(0.5 dB step)
SW 0 dB
Dynamic range compressor
[D. RANGE]
COMP. MAX, COMP. STD,
COMP. AUTO, COMP. OFF
COMP.
AUTO
continued
To Next Page
