Sony STR-DA3500ES User Manual

78
US
D:\NORM'S JOB\SONY HA\SO0046\STR-DA3500ES\U VERSION\US\4144907111\01US-
STRDA3500ESUC\080TUN.fm
masterpage: Left
STR-DA3500ES
4-144-907-11(1)
3 Press V/v repeatedly to select
the category, then press .
• ALL: You can select a channel from all
the categories.
• (category name): You can select a
channel from one category.
When the “Preset Mode” screen is
displayed, press OPTIONS, then press
V/v repeatedly to select “Category
Mode”.
4 Press V/v to select the channel,
then press .
The selected channel is being received.
The channel information is displayed on
the TV screen.
Note
When you select a channel in the “Category Mode”,
the channel you selected may not be the one in the
category you want. This is because one channel may
belong to more than one category.
1 Press GUI MODE repeatedly to
select “GUI ON”.
The GUI menu appears on the TV screen.
Press MENU if the GUI menu does not
appear on the TV screen.
2 Press V/v repeatedly to select
“XM” or “SIRIUS”, then press
or b.
3 Press OPTIONS.
4 Press V/v to select “Direct
Tuning”, then press .
5 Press SHIFT, then press the
numeric buttons to enter the
channel number.
6 Press .
The selected channel is tune in.
XM
SIRIUS
Selecting a channel by inputting
the channel number directly
MENU
GUI
MODE
OPTIONS
,
V/v/B/b
Numeric
buttons
SHIFT

Sony STR-DA3500ES Specifications

General

Display	-
Equalizer	Yes
Product color	Black
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.09 %
Supported radio bands	AM, FM
I/O ports	5 x A/V In 1 x A/V Out 1 x Monitor Out 4 x Opt. In 1 x Opt. Out 3 x Coax. 4 x Audio In 1 x Audio Out 1 x DM 4 x HDMI In 1 x HDMI Out 1 x Digital In
Connectivity technology	Wired
Headphone outputs	1
Headphone connectivity	3.5 mm
Dimensions (WxDxH)	430 x 388 x 157.5 mm

Weight and Dimensions

Weight	12500 g
