Amplifier Operations
Settings for the video
(Video settings menu)
You can use the Video settings menu to make
settings for video. Select “Video” in the
Settings menu. For details on adjusting the
parameters, see “7: Operating the receiver
using the GUI (Graphical User Interface)”
(page 40).
x Resolution
(Video signals conversion)
Lets you convert the resolution of analog video
input signals.
•DIRECT
•AUTO
• 480i/576i
• 480p/576p
• 720p
• 1080i
• 1080p
For details on operation, see “In the video
input/output conversion table classified by the
menu settings” (page 35).
Settings for HDMI
(HDMI settings menu)
You can use the HDMI settings menu to make
the required settings for components
connected to the HDMI jack. Select “HDMI”
in the Settings menu. For details on adjusting
the parameters, see “7: Operating the receiver
using the GUI (Graphical User Interface)”
(page 40).
x Control for HDMI
(Control for HDMI)
Lets you turn the components connected to the
HDMI jack using an HDMI cable on or off.
•OFF
•ON
For details on operation, see “Using
“BRAVIA” Sync features” (page 84).
Note
When you set “Control for HDMI” to “ON”, “Audio
Out” may be changed automatically.
x Audio Out
(HDMI audio input setting)
Lets you set the audio output for HDMI from
the playback component connected to the
receiver via an HDMI connection.
• TV+AMP
The sound is output from the TV speaker and
the speakers connected to the receiver.
Notes
• The sound quality of the playback component
depends on the TV’s sound quality, such as the
number of channels, the sampling frequency, etc.
When the TV has stereo speakers, the sound
output from the receiver is also stereo as that of
the TV, even if you play multi channel source.
• When you connect the receiver to a video
component (projector, etc.), sound may not be
output from the receiver. In this case, select
“AMP”.
• When you select the input that you have assigned
the HDMI input, sound does not output from the
TV.
Video settings menu parameters
HDMI settings menu parameters
continued

Sony STR-DA3500ES Specifications

General

Display	-
Equalizer	Yes
Product color	Black
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.09 %
Supported radio bands	AM, FM
I/O ports	5 x A/V In 1 x A/V Out 1 x Monitor Out 4 x Opt. In 1 x Opt. Out 3 x Coax. 4 x Audio In 1 x Audio Out 1 x DM 4 x HDMI In 1 x HDMI Out 1 x Digital In
Connectivity technology	Wired
Headphone outputs	1
Headphone connectivity	3.5 mm
Dimensions (WxDxH)	430 x 388 x 157.5 mm

Weight and Dimensions

Weight	12500 g
